SolarDirect
51.2V 560Ah 28.7kWh LFP Floor-Standing Battery Cabinet
$6499.99
The SolarDirect 28.7kWh LFP Floor Cabinet is a mid-scale industrial ESS for light manufacturing, retail centers, agricultural operations, and commercial buildings. Integrates 560Ah of LiFePO4 cells, embedded BMS, LCD touchscreen, and ventilation cooling in a floor-standing IP55-rated enclosure. Applications: peak demand shaving (reducing 15-minute interval peak charges), emergency backup for critical loads (servers, HVAC, refrigeration), and solar self-consumption optimization on time-of-use rates. Specs: 51.2V nominal, 28.7kWh gross / 25.8kWh usable, 300A continuous charge/discharge, operating range -20°C to +55°C. Pre-wired with 150A AC circuit breaker, 3-phase AC and DC disconnect, and SPD surge protection. Modbus TCP/IP over LAN for SCADA/BMS integration. This is a configured-to-order product — SolarDirect will contact you within 24 hours to confirm specifications and shipping. ⚠️ Certification note: CE marked, IEC 62619, IEC 62477 compliant, UN38.3 transport certified. NOT UL 1973 listed. AHJ compliance documentation available on request.
Specifications
| cycles | 6000 |
| chemistry | LiFePO4 |
| ip_rating | IP55 |
| voltage_v | 51.2 |
| weight_kg | 320 |
| usable_kwh | 25.8 |
| capacity_ah | 560 |
| form_factor | floor-standing cabinet |
| capacity_kwh | 28.7 |
| communication | Modbus TCP/IP,RS485,CAN |
| dimensions_mm | 1200 × 600 × 1000 |
| operating_temp | -20°C to +55°C |
| bms_continuous_a | 300 |
