Jinko Tiger Neo 605W N-Type TOPCon Solar Panel (JKM605N-72HL4-V)

The Jinko Tiger Neo JKM605N-72HL4-V is a commercial-grade 605W N-Type TOPCon module built for utility-scale ground-mount, commercial rooftops, and high-performance residential arrays paired with 1500V DC string inverters. HOT 2.0 (High-density Overlay Technology) increases cell density by 7% over prior generation, driving module efficiency to 22.00%. N-Type eliminates Light-Induced Degradation (LID) and Light and Elevated Temperature-Induced Degradation (LeTID) — first-year degradation ≤1.0% versus 2–3% for P-type PERC, with just 0.4%/yr linear thereafter to a 87.4% Year 30 guarantee. Key electrical specs at STC: Pmax 605W, Vmpp 45.42V, Impp 13.32A, Voc 52.50V, Isc 13.95A. Temperature coefficient (Pmax) −0.30%/°C — outperforms PERC (−0.34%/°C) in hot climates. Max system voltage 1500V DC. Dual-glass option (glass-glass) available for extended lifetime in corrosive or humid environments. SMBB (Super Multi-Busbar) technology reduces internal series resistance, boosts low-light performance, and improves shade tolerance. Wind load 2400 Pa, snow load 5400 Pa. Warranty: 12-year product warranty, 30-year linear power warranty (87.4% at Year 30). IEC 61215:2021 + IEC 61730:2023 certified. UL 61730 listed (US/Canada). Suitable for 1500V commercial systems with Huawei SUN2000, SMA Sunny Tripower, Fronius Symo/Primo GEN24, Solis, and Deye three-phase string inverters.
